Ubiquiti PBE-5AC-500 PowerBeam – 5 GHz 27 dBi High-Performance airMAX ac Bridge for Long-Range Outdoor Wireless Links

Ubiquiti PBE-5AC-500 PowerBeam ac High-Performance airMAX Bridge Outdoor Antenna The Ubiquiti PowerBeam PBE-5AC-500 is a high-performance outdoor airMAX bridge designed for long-distance, point-to-point (PtP) wireless links. Operating at 5 GHz with a 27 dBi gain, this PowerBeam delivers over 450 Mbps throughput and a link range exceeding 25 km. It features improved mounting hardware, a dedicated WiFi management radio, and an integrated spectral analysis radio for network optimization and monitoring. The PowerBeam’s compact dish design focuses RF energy for improved noise immunity in dense deployments. Built with UV-stabilized plastic and tested against wind, vibration, UV exposure, and extreme temperatures, the PBE-5AC-500 ensures stable and reliable performance in outdoor environments. ✅ Specifications: 🛠 Mechanical: Specification Details Dimensions 520 x 520 x 308 mm (without radome) Weight 2.35 kg (without radome), 3.2 kg (with) Enclosure Material UV-stabilized plastic Mounting Pole mount kit (included) Wind Loading 264.6 N at 96 km/h Wind Survivability 96 km/h (60 mph) ⚙️ Hardware: Specification Details Networking Interface (1) GbE RJ45 Port Power Method Passive PoE (2-pair) Power Supply 24V, 0.5A PoE Adapter (included) Voltage Range 20–27V DC Max Power Consumption 8.5W ESD/EMP Protection ±24 kV Air/Contact LEDs Power, LAN, 4x WLAN, Signal Strength 📡 Wireless: Specification Details Gain 27 dBi Max VSWR 1.5:1 Channel Sizes PtP: 10–80 MHz / PtMP: 10–40 MHz Polarization Dual Linear Frequency (Worldwide) 5150–5875 MHz Frequency (USA) U-NII-1, 2A, 2C, 3 🧪 Environmental & Certifications: Operating Temp: -40°C to 70°C Humidity: 5–95% non-condensing Salt Fog: IEC 68-2-11 (ASTM B117) UV Resistance: IEC 68-2-5 Vibration & Temperature Shock: IEC tested Rain & Dust: MIL-STD-810G equivalent Certifications: FCC, IC, CE, RoHS
