TP-Link EAP115 Indoor | 300Mbps Wireless N Ceiling Mount Access Point

EAP115 300Mbps Wireless N Ceiling Mount Access Point HARDWARE FEATURES Interface 1× Fast Ethernet (RJ-45) Port (Support IEEE802.3af PoE) Button Reset Power Supply 802.3af PoE or external 9VDC/0.6A power supply Max. Power Consumption 2.8 W Dimensions ( W x D x H ) 7.5×6.8×1.2 in (189.4×172.3×29.5mm) Antenna Internal 2× 4 dBi Omni Mounting Ceiling /Wall Mounting (Kits included) WIRELESS FEATURES Coverage 60㎡(650ft²) Concurrent Clients 100+ Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b Frequency 2.4–2.4835 GHz Signal Rate • 11n: Up to 300Mbps(dynamic) • 11g: Up to 54Mbps(dynamic) • 11b: Up to 11Mbps(dynamic) Reception Sensitivity • 300M: -71dBm@10% PER • 150M: -75dBm@10% PER • 54M: -78dBm@10% PER • 11M: -93dBm@8% PER • 6M: -92dBm@10% PER • 1M: -96dBm@8% PER Wireless Functions • Multiple SSIDs (Up to 8 SSIDs) • Enable/Disable Wireless Radio • Automatic Channel Assignment • Transmit Power Control (Adjust Transmit Power on dBm) • QoS(WMM) • Rate Limit • Reboot Schedule • Wireless Schedule • Wireless Statistics based on SSID/AP/Client Wireless Security • Captive Portal Authentication • Access Control • Wireless MAC Address Filtering • Wireless Isolation Between Clients • SSID to VLAN Mapping • Rogue AP Detection • 802.1X Support • 64/128/152-bit WEP / WPA / WPA2-Enterprise,WPA-PSK / WPA2-PSK Transmission Power • CE: ≤19 dBm (EIRP) • FCC: ≤21 dBm Management Features Omada App Yes Centralized Management • Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller Cloud Access Yes (Through OC300, OC200, or Omada Software Controller) Email Alerts Yes LED ON/OFF Control Yes Management MAC Access Control Yes SNMP v1,v2c System Logging Local/Remote Syslog Local/Remote Syslog SSH Yes Web-based Management HTTP/HTTPS L3 Management Yes Multi-site Management Yes Management VLAN Yes OTHERS Certification CE, FCC, RoHS Package Content • 300Mbps Wireless N Ceiling Mount Access Point EAP115 • Power Adapter • Mounting Kits • Installation Guide System Requirements Microsoft Windows 11/10/8/7/Vista/XP, Linux Environment • Operating Temperature: 0–40 ℃ (32–104 ℉) • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing
