Mikrotik LHG XL HP5 RBLHG-5HPnDMikrotik LHG XL HP5 RBLHG-5HPnD-XL – Long-Range 5 GHz Wireless CPE for Outdoor Networks-XL

Mikrotik LHG XL HP5 RBLHG-5HPnD-XL – Long-Range 5 GHz Wireless CPE for Outdoor Networks The LHG is a compact and light 5GHz 802.11 a/n wireless device with an integrated dual polarization 24.5 dBi grid antenna. LHG HP5 comes with two times more output power than our regular LHG 5, and is designed to reach up to 60% longer distances. The grid design ensures protection against wind, and the fact that the antenna element is built into the wireless unit means no loss on cables. We have two versions available. LHG HP5-US (USA) is factory locked for 5170-5250MHz and 5725-5835MHz frequencies. This lock can not be removed. LHG HP5 (International) supports 5150MHz-5875MHz range (Specific frequency range can be limited by country regulations). Powering Details Number of DC inputs 1 (PoE-IN) Max power consumption 7 W Cooling type Passive PoE in Passive PoE PoE in input Voltage 10-28 V Wireless specifications Details Wireless 5 GHz Max data rate 300 Mbit/s Wireless 5 GHz number of chains 2 Wireless 5 GHz standards 802.11a/n Antenna gain dBi for 5 GHz 24.5 Wireless 5 GHz chip model AR9344 Wireless 5 GHz generation Wi-Fi 4 Ethernet Details 10/100 Ethernet ports 1 Certification & Approvals Details Certification CE, FCC, IC, EAC, ROHS Wireless specifications 5 GHz Transmit (dBm) Receive Sensitivity 6MBit/s 28 -96 54MBit/s 25 -80 MCS0 28 -96 MCS7 24 -75
