Grandlink GLK12 fiber optic fusion splicer splicing machine

GLK-12 High Performance Optical Fiber Splicing Machine The Grandlink GLK-12 Splicing Machine offers a perfect balance of performance and durability for fiber technicians. Designed for FTTH and outdoor operations, this machine delivers fast, accurate, and stable splicing results in every environment. Moreover, it features a powerful 4-motor core alignment system that ensures high precision during fusion. With 380X zoom magnification and a high-resolution 4.3-inch touchscreen, users can clearly observe the fiber core, making the splicing process highly efficient. In addition to its powerful hardware, the GLK-12 boots up in just 3 seconds, reducing waiting time. The intuitive interface, supported by dual-camera imaging, makes it easier to operate—even for beginners. Therefore, it is a reliable choice for telecom professionals seeking speed and ease of use. Splicing Machine Specifications: Specification Details Splice Time 6 seconds Heating Time 18 seconds Zoom Magnification 380X Battery Capacity 5200mAh Display Size 4.3-inch LCD Touchscreen Boot Time 3 seconds Memory 60,000 Records + 6,000 Images Interfaces USB2.0, Type-C Fiber Types G651, G652, G653, G655, G657 Splice Modes 500 Customizable Modes Heat Modes 200 Customizable Modes Weight 2.5Kg approx. Size 205mm × 134mm × 102mm Battery & Charging: Battery Capacity: 5200mAh large lithium battery Usage: Supports 200 cycles of splice + heating on a single charge Charging Port: USB Type-C (Fast charging supported) Environmental Resistance: Operates in -40°C to +80°C Works reliably at altitudes up to 5000 meters Dustproof, shockproof, and waterproof design for rugged use What’s in the Box (Full Kit): 1 × GLK-12 Host Machine (with Battery) 1 × Precision Cleaver 1 × AC Adapter & Charging Cable 1 × V-Groove Cleaning Brush 1 × Leather Wire Stripper 1 × Miller Tool 1 × Alcohol Bottle 1 × Instruction Manual & Warranty Card 1 × Portable Carry Bag 1 × High-strength Transport Case 1 × Certificate & QC Report 1 × Cooling Tray & Straps 2 × Electrodes
