CP PLUS CP-DPS-PD08V3-12D 8 Channel Power Supply – 12V DC Output, CCTV Camera Power Distribution Box, Metal Enclosure, Overload & Short-Circuit Protection

The CP PLUS CP-DPS-PD08V3-12D 8 Channel Power Supply is built for stable 12V DC output in CCTV and security systems. It offers 60W power with short-circuit, over-voltage, and over-current protection. With 2+2 output terminals, it simplifies camera installation. The unit includes a cable compensation switch with 3 modes to handle voltage drops. An LED power indicator and EMI filter ensure clean and safe operation. It comes in a shock-proof plastic housing, and supports both wall-mount and desktop setups. Ideal for small to medium surveillance networks. Input voltage 200 ~ 240VAC Input AC Frequency Range 47 ~ 63Hz Input Current (Typ.) 1A/230VAC Power Cord 2 Pin (L & N) Standby Power Consumption ≤0.5W Inrush Current (Typ.) ≤40A@230VAC Efficiency (Typ.) 85% Output voltage Normal Mode 12V Output Current range Normal Mode 0 ~ 5.0A Rated Power Normal Mode 60W Ripple & Noise (max.) ≤240mV Line Regulation 2% Load Regulation 3% Power On Indicator Support Cable Compensation Switch Support, 3 Modes (Normal, Long, Ex. Long) No. of Output Ports 2 output terminals short-circuit protection Support Dielectric Strength (Hi-pot) 3.0KV Insulation Resistance 100MΩ@500VDC Surge Immunity 1.0KV Operating Temperature -10 ~ +45°C Operating Humidity 20 ~ 90% RH Non-condensing Storage Temperature -10 ~ +45°C Storage Humidity 10 ~ 95% RH Dimension 141.5mm x 102.6mm x 33.2mm Weight 0.234kg without Power Cord and Packing Box
