CCTV- Camera TP-Link VIGI C540S

TP-Link VIGI C540S Outdoor ColorPro Night Vision The TP-Link VIGI C540S is a 4MP outdoor pan-tilt camera with ultra-low light night vision, 360° coverage, and smart detection for human and vehicle alerts. It features active defense with sound and light alarms, two-way audio, H.265+ compression for storage efficiency, and IP66 waterproofing for reliable outdoor performance. The TP-Link VIGI C540S camera offers ultra-low light color night vision, capturing clear 4MP video even in darkness. With 360° monitoring, it eliminates blind spots and uses face recognition, people/vehicle analytics, and human/vehicle classification for enhanced security and efficient search. Smart detection alerts for intrusions, true WDR provides clarity in high contrast, and active defense deters intruders with sound and light. Two-way audio allows real-time communication, H.265+ compression optimizes storage, and IP66 waterproofing ensures durable outdoor use. Brand Name TP-Link Model Name VIGI C540S Dimension(cm) 24X24X16 Weight(kg) 1.16 CAMERA Image Sensor 1/1.79” Progressive Scan CMOS Shutter Speed 1/3 to 1/10000 s Slow Shutter Yes Minimum Illumination 0.0005 Lux; 0 Lux with White Light Day/Night Mechanism N/A Day/Night Switch Unified/Scheduled/Auto LENS Type Fixed Focal Lens Focal Length 4 mm Aperture F1.0±5% FOV 4mm: Horizontal FOV: 104°, Vertical FOV: 55°, Diagonal FOV: 127° Lens Mount M16*P 0.5 DORI Distance 4 mm: Detect: 63 m (207 ft) Observe: 26 m (86 ft) Recognize: 13m (41 ft) Identify: 6 m (21 ft) PTZ Pan/tilt Range Pan: 0° to 348°, Tilt: 0° to 105° Pan/tilt Speed Pan Speed: Configurable from 8° to 44°/s; Preset Speed: 44°/sTilt Speed: Configurable from 8° to 44°/s, Preset Speed: 44°/s Manual Control Speed Configurable from 8° to 35°/s Presets 300 Patrol Scan 8 patrols, up to 8 presets for each patrol Power-off Memory Yes; Auto restore to previous PTZ and lens status after power failure Park Action Yes; Preset; Patrol Scan 3D Positioning Yes ANGLE ADJUSTMENT (MANUAL) Range Pan: 0° to 348° Tilt: 0° to 105° ILLUMINATOR IR LED N/A White LED Quantity: 2 Range: 30m Illuminator On/Off Control Auto/Scheduled/Always on/Always off VIDEO Max. Resolution 2688 x 1520 Main Stream Frame Rate: 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fpsResolution: 2688×1520, 2560×1440, 2304×1296, 2048×1280, 1920×1080, 1280×720 Sub-Stream Frame Rate: 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fpsResolution: 704×576, 640×480, 352×288, 320×240 Bit Rate Control CBR, VBR Video Compression Main Stream: H.265+/H.265/H.264+/H.264 Sub-Stream: H.265/H.264 H.264 Type Main Profile/High Profile H.264+ Main Stream Supported H.265 Type Main Profile H.265+ Main Stream Supported Video Bit Rate Main Stream: 256 Kbps to 6 Mbps Sub-Stream: 64 Kbps to 512 Kbps IMAGE Image Settings Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software Image Enhancement BLC/3D DNR/HLC Wide Dynamic Range 120dB Note: When Face Recognition s is enabled, only DWDR is supported. SNR ≥ 52 dB Image Parameters Switch Yes Privacy Mask Up to 4 Masks ROI 1 Region OSD Setting Yes AUDIO Audio Communication Two-Way Audio Audio Input Yes Audio Output Yes Audio Compression Yes Audio Sampling Rate 8KHz Environment Noise Filtering Yes Audio Bit Rate 64 Kbps(G.711 alaw) NETWORK Protocol TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS ONVIF Yes API ONVIF Simultaneous Live View 3 Main Streams & 3 Sub-Streams Client VIGI App, VIGI Security Manager, Web UI Web Browser Google Chrome® 57 and above Firefox® 52 and above Safari® 11 and above Microsoft® Edge 91 and above Cloud Yes Security Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication ALARM AND EVENT MANAGEMENT Smart Event Human & Vehicle Classification, Intrusion Detection, Line-Crossing Detection, People Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Abandoned Object Detection, Object Removal Detection, Loitering Detection, Scene Change Detection, Smart Frame Basic Event Motion Detection, Video Tampering Detection, Exception ( Illegal Login) Alarm Linkage Memory Card Video Recording, Message Push, Audible Warning, White Light Flashing Linkage Method N/A Output Notification Message Push DEEP LEARNING FUNCTION People & Vehicle Analytics Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier. Face Capture Support Face Comparison Support INTERFACES Network Interface 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE Alarm N/A Reset Button Yes Power DC Power Port On-board Storage Built-In Memory Card Slot, Support MicroSD Card, Up to 256 GB Built-in Microphone Yes; Records Anything Going on within a 15-ft Radius of the Camera Built-in Speaker Yes Audio N/A GENERAL Operating Temperature -30–60 °C Storage Temperature -40–60 °C Operating Humidity 95% or Less (Non-Condensing) Storage Humidity 95% or Less (Non-Condensing) Package Contents VIGI Network Camera Quick Start Guide Waterproof Cable Attachments Mounting Accessories Material Plastic Power Supply 12V DC ± 5%, Max. 13.13 W, 5.5mm Coaxial Power Plug PoE: 802.3at, class 4, Max. 16.47 W Protection IP66 Product Dimensions (L x W x H) 120 × 172 × 203 mm Certifications CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC WARRANTY & MANUFACTURER DETAILS Country of Origin China Manufacturer Details TP-Link Corporation Limited, Kowloon, Hong Kong Importer Details TP-Link India Private Limited, Palghar, Vasai, 401208 Packer Details TP-Link India Private Limited, Palghar, Vasai, 401208
