CCTV- Camera TP-Link VIGI C350 5MP 2.8mm

TP-Link VIGI C350 5MP 2.8mm Outdoor Full-Color Bullet Network Camera The TP-Link VIGI C350 is a 5MP bullet network camera with 5MP Super-High Definition,24h Full-Color, Human & Vehicle Classification, Smart Detection, People & Vehicle Analytics,Active Defense, Two-Way Audio, P67 Waterproof,H.265+ compression The TP-Link VIGI C350 5MP Outdoor Full-Color Bullet Network Camera offers ultra-clear 5MP video with full-color night vision, human and vehicle detection, and active defense through sound and light alerts. It supports two-way audio, IP67 waterproofing, and efficient H.265+ compression to save storage and bandwidth. Advanced video enhancement includes features like Smart IR, True WDR, and 3D DNR. Multiple management options (web UI, NVR UI, app, and security manager) and up to 512GB local SD storage make it flexible and user-friendly. Brand Name TP-Link Model Name VIGI C350 Dimension(cm) 25X15X11 Weight(kg) 0.58 CAMERA Image Sensor 1/2.7” Progressive Scan CMOS Shutter Speed 1/3 to 1/10000 s Slow Shutter Yes Minimum Illumination 0.005 Lux; 0 Lux with IR/white light Day/Night Mechanism IR Cut Filter Day/Night Switch Unified/ Scheduled/ Auto LENS Type Fixed Focal Lens Focal Length 2.8 mm Aperture F1.6 FOV 2.8mm: Horizontal FOV: 109°, Vertical FOV: 57°, Diagonal FOV: 128° Lens Mount M12*P 0.5 DORI Distance 2.8 mm Detect: 63 m (206 ft) Observe: 26 m (85 ft) Recognize: 12 m (39 ft) Identify: 6 m (19 ft) ANGLE ADJUSTMENT (MANUAL) Range Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360° ILLUMINATOR IR LED Quantity: 2 Range: 30m Wavelength: 850nm White LED Quantity: 2 Range: 30m Illuminator On/Off Control Auto/Scheduled/Always on/Always off VIDEO Max. Resolution 2880 X 1620 Main Stream Frame Rate： 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fpsResolution: 2880×1620,2688×1520, 2304×1296, 2048×1280, 1920×1080,1280x720Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. Sub-Stream Frame Rate： 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fpsResolution: 704×576,640×480, 352×288, 320x240Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. Bit Rate Control CBR, VBR Video Compression Main Stream: H.265+/H.265/H.264+/H.264 Sub-Stream: H.265/H.264 H.264 Type Main Profile/High Profile H.264+ Main Stream Supported H.265 Type Main Profile△ H.265+ Main Stream Supported△ Video Bit Rate Main Stream: 256 Kbps to 6 Mbps Sub-Stream: 64 Kbps to 512 Kbps IMAGE Image Settings Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software Image Enhancement BLC/3D DNR/HLC/SmartIR Wide Dynamic Range 120 dB Note: When People & Vehicle Analytics is enabled, only DWDR is supported. SNR ≥ 52 dB Image Parameters Switch Yes Privacy Mask Up to 4 Masks ROI 1 Region OSD Setting Yes AUDIO Audio Communication Two-Way Audio Audio Input Yes Audio Output Yes Audio Compression Yes Audio Sampling Rate 8KHz Environment Noise Filtering Yes Audio Bit Rate 64 Kbps(G.711 alaw) NETWORK Protocol TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP ONVIF Yes API Open Network Video Interface (Profile S) Simultaneous Live View 3 Main Streams & 3 Sub-Streams Client VIGI App, VIGI Security Manager Web Browser Google Chrome® 57 and above Firefox® 52 and above Safari® 11 and above Microsoft® Edge 91 and above Cloud Yes Security Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication ALARM AND EVENT MANAGEMENT Smart Event Human & Vehicle Classification, Area Intrusion Detection, Line-Crossing Detection, People Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection, Loitering Detection, Abnormal Sound Detection, Scene Change Detection Basic Event Motion Detection, Video Tampering Detection, Exception ( Illegal Login) Alarm Linkage Memory Card Video Recording, Message Push, Audible Warning, White Light Flashing Linkage Method N/A Output Notification Message Push DEEP LEARNING FUNCTION People & Vehicle Analytics Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier. Face Capture N/A Face Comparison N/A INTERFACES Network Interface 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE Alarm N/A Reset Button Yes Power DC Power Port On-board Storage Built-In Memory Card Slot, Support MicroSD Card, up to 512 GB Built-in Microphone Yes; Records Anything Going on within a 15-ft Radius of the Camera Built-in Speaker Yes Audio N/A GENERAL Operating Temperature -30–60 °C Storage Temperature -40–60 °C Operating Humidity 95% or Less (Non-Condensing) Storage Humidity 95% or Less (Non-Condensing) Package Contents VIGI Network Camera Quick Start Guide Waterproof Cable Attachments Mounting Accessories Material Plastic Power Supply 12V DC ± 5%, Max. 9 W, 5.5 mm Coaxial Power Plug PoE: 802.3af/at, class 0, Max. 10.5 W Protection IP67 Product Dimensions (L x W x H) 78.5× 188.0× 71.5 mm (3.09× 7.40× 2.81 in) Certifications CE, NTRA, VCCI, KC, BSMI, FCC, IC WARRANTY & MANUFACTURER DETAILS Country of Origin China Manufacturer Details TP-Link Corporation Limited, Kowloon, Hong Kong Importer Details TP-Link India Private Limited, Palghar, Vasai, 401208 Packer Details TP-Link India Private Limited, Palghar, Vasai, 401208
