CCTV- Camera TP-Link VIGI C230I MINI

TP-Link VIGI C230I Mini IP Camera 2.8mm Lens The Tp-link VIGI C230I Mini 3MP Camera provides clear imaging, human/vehicle detection, and smart alerts. Compact with an ultra-wide lens, it’s ideal for tight spaces. IK08 vandal-proof, with H.265+ compression, Smart IR, WDR, and Corridor Mode for optimized narrow-area monitoring. Tp-link VIGI C230I Mini 3MP Camera offers high-definition clarity, human/vehicle detection, and smart alerts. Compact with an ultra-wide 2.8mm lens, it’s ideal for tight spaces like corridors and elevators. The IK08 vandal-proof design enhances durability, while H.265+ compression, Smart IR, WDR, 3D DNR, and Night Vision improve video quality. Corridor Mode optimizes monitoring of narrow areas. 3MP Super-High Definition: The VIGI C230I Mini camera comes with 3MP—more than enough pixels to pick up some of the more discrete details. Human & Vehicle Classification: Distinguishes humans and vehicles from other objects, so you receive more accurate event notifications. Smart Detection: Receive notifications and check feeds when someone crosses a boundary, enters an area you’ve set, obstructs the camera, or removes/abandons objects. Small but compact with wide views: With a small, compact form factor and a 2.8 mm ultra-wide angle lens, the VIGI C230I Mini camera is ideal for corridors, elevators, small warehouses, and convenience stores, where space is limited and a wide view is required. IK08 Vandal-Proof: Equipped with a vandal-proof dome encasing, the VIGI C230I Mini dome camera withstands damage and provides more reliable security protection in important scenarios, such as ATMs, corridors, and checkout counters. H.265+: Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality. Smart Video Enhancement: VIGI’s professional technologies process videos to greatly improve their quality that is vital to your monitoring, including Smart IR, WDR, 3D DNR, and Night Vision. Corridor Mode: Allows you to change the image aspect ratio from 16:9 to 9:16, and helps to monitor long and narrow areas. Brand Name TP-Link Model Name VIGI C230I Mini Dimension(cm) 19X15X12 Weight(kg) 0.48 CAMERA Image Sensor 1/2.8” Progressive Scan CMOS Shutter Speed 1/3 to 1/10000 s Slow Shutter Yes Aperture F1.6 Lens 2.8 mm Lens Mount M12 Minimum Illumination Color: 0.1 Lux; 0 Lux with IR Day/Night Mechanism IR Cut Filter Day/Night Switch Unified/ Scheduled/ Auto Digital Noise Reduction 3D DNR WDR DWDR IR Working Distance 30m Viewing Angle Horizontal FOV: 106.9°, Vertical FOV:56.9°, Diagonal FOV: 127.9° LENS Type Fixed Focal Lens Focal Length 2.8 mm Aperture F1.6 FOV 2.8mm: Horizontal FOV: 106.9°, Vertical FOV:56.9°, Diagonal FOV: 127.9° Lens Mount M12 DORI Distance 2.8mm ; Detect: 49 m (161 ft) Observe: 20 m (67 ft) Recognize: 10 m (32 ft) Identify: 5 m (16 ft) ANGLE ADJUSTMENT (MANUAL) Range Pan: -30° to 30° Tilt: 0° to 85° Rotate: -15° to 15° ILLUMINATOR IR LED Quantity: 2 Range: 30m Wavelength: 850nm White LED N/A Illuminator On/Off Control Auto/Scheduled/Always on/Always off VIDEO Max. Resolution 2304 × 1296 Main Stream Frame Rate： 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fpsResolution: 2304×1296, 2048×1280, 1920×1080,1280x720Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. Sub-Stream Frame Rate： 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fpsResolution: 704×576, 640×480, 352×288, 320x240Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. Bit Rate Control CBR, VBR Video Compression Main Stream: H.265+/H.265/H.264+/H.264 Sub-Stream: H.265/H.264 H.264 Type Main Profile/High Profile H.264+ Main Stream Supported H.265 Type Main Profile H.265+ Main Stream Supported Video Bit Rate Main Stream: 256 Kbps to 4 Mbps Sub-Stream: 64 Kbps to 512 Kbps IMAGE Image Settings Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, HLC Adjustable by Client Software, Rotation (90°/270°) Image Enhancement BLC/3D DNR/HLC/SmartIR Wide Dynamic Range DWDR SNR ≥ 52 dB Image Parameters Switch Yes Privacy Mask Up to 4 Masks ROI 1 Region OSD Setting Yes AUDIO Audio Communication Two-Way Audio Audio Input Yes Audio Output Yes Audio Compression Yes Audio Sampling Rate 8KHz Environment Noise Filtering Yes Audio Bit Rate 64 Kbps(G.711 alaw) NETWORK Protocol TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS ONVIF Yes API ONVIF Simultaneous Live View 3 Main Streams & 3 Sub-Streams Client VIGI App, VIGI Security Manager, VIGI NVR, Web Web Browser Open Network Video Interface (Profile S) Cloud Yes Security Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication ALARM AND EVENT MANAGEMENT Smart Event Human & Vehicle Classification, Area Intrusion Detection, Line-Crossing Detection, People Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection Basic Event Motion Detection, Video Tampering Detection, Exception ( Illegal Login) Alarm Linkage Memory Card Video Recording, Message Push, Audible Warning Linkage Method N/A Output Notification Message Push INTERFACES Network Interface 1 RJ45 10/100M Self-Adaptive Ethernet Port Alarm N/A Reset Button Yes Power DC Power Port Button Reset Button Video Output – On-board Storage Built-In Memory Card Slot, Support MicroSD Card, Up to 256 GB Built-in Microphone Yes Built-in Speaker Yes Audio N/A GENERAL Operating Temperature -30–60 °C Storage Temperature -40–60 °C Operating Humidity 95% or Less (Non-Condensing) Storage Humidity 95% or Less (Non-Condensing) Package Contents VIGI Network Camera Quick Start Guide Mounting Accessories Mounting Template Dimensions( H X W X D ) 114 × 114 × 58 mm Material Plastic General Features Two Streams, Mirror, Privacy Masks, Password Reset via E-mail, HTTP Listening Net Weight 0.23 kg Gross Weight 0.41 kg Power Consumption 12V DC: Max 7.5W PoE: Class 0 Power Supply 12V DC ± 5%, 5.5mm Coaxial Power Plug PoE (802.3af/at, class 0) Vandal Resistant IK08 Protection IK08 Product Dimensions (L x W x H) 114× 58× 114 mm Certifications CE/VCCI/BSMI/KC/ONVIF VIDEO/IMAGE Video Compression Main Stream: H.265+/H.265/H.264+/H.264 Sub-Stream: H.265/H.264 Frame Rate & Resolutions Main Stream: Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Resolution: 2304×1296, 2048×1280, 1920×1080, 1280×720 Sub-Stream: Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Resolution: 704×576, 640×480, 352×288, 320×240 Max. Resolution 3MP (2304 × 1296) Video Streaming 3 Main Streams 3 Sub-Streams Image Settings Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software, Rotation(90°/270°) Image Enhancement BLC/3D DNR/HLC/SmartIR Video Bit Rate 64 Kbps to 4 Mbps Day/Night Switch Day/Night/Auto/Schedule SMART FEATURE-SET Smart Event Human & Vehicle Classification, Intrusion Detection, Line-Crossing Detection, Human Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection Basic Event Motion Detection, Camera Tampering Detection, Exception (Illegal Login) Linkage Method Trigger Notification: ONVIF, HTTPS Region of Interest 1 Region WARRANTY & MANUFACTURER DETAILS Country of Origin China Manufacturer Details TP-Link Corporation Limited, Kowloon, Hong Kong Importer Details TP-Link India Private Limited, Palghar, Vasai, 401208 Packer Details TP-Link India Private Limited, Palghar, Vasai, 401208
